1. Chinese manual for German E+H electromagnetic flowmeter: [4]

The Chinese manual for German E+H electromagnetic flowmeter mainly introduces the usage method of the product and common troubleshooting solutions. Usage: Installation: The flow meter should be installed on a horizontal or vertical pipe side, ensuring that the fluid direction is consistent with the direction indicated by the flow meter. The installation position should avoid vibration and strong magnetic field interference, and the length of the front and rear straight pipe sections should meet the requirements (usually 5D in the front and 3D in the back, where D is the pipe diameter) to ensure measurement accuracy. Wiring: Connect the power supply, signal output, and grounding wire according to the wiring diagram in the instruction manual. Ensure that the wiring is secure and avoid poor contact. The grounding resistance should be less than the specified value (such as 100 Ω) to reduce interference. Parameter setting: Set the flow meter parameters, including range, unit, output signal type, etc., through the operation panel or upper computer software. After the setting is completed, verification is required to ensure the accuracy of the parameters. Operation: After starting the fluid, observe whether the flow meter displays stability. Regularly check the stability of the zero point and perform zero point calibration if necessary. Common troubleshooting solutions: No display or abnormal display: Check if the power supply is normal and if the wiring is loose. If the power supply is normal, it may be a display screen malfunction and needs to be replaced by contacting after-sales service. Inaccurate flow measurement: Check whether the fluid is filled

User Manual for Electromagnetic Flow Meter

in the pipeline and whether there are bubbles or eddies. Adjust the length of the straight pipe section before and after adjustment, or recalibrate the flowmeter. Unstable output signal: Check if the grounding is good to avoid electromagnetic interference. If the signal is still unstable, it may be a sensor malfunction and requires maintenance or replacement. Zero drift: Regularly perform zero calibration. If the zero point drifts frequently, it may be due to changes in pipeline pressure or fluid properties, and parameters need to be adjusted or recalibrated. Maintenance and upkeep: Regular cleaning: Clean the dirt on the inner wall and electrodes of the flowmeter to avoid affecting measurement accuracy. When cleaning, it is necessary to turn off the fluid and use specialized cleaning agents. Check sealing: Regularly inspect the connection of the flowmeter for air or water leakage to ensure good sealing. Storage environment: When not in use for a long time, the flowmeter should be stored in a dry and ventilated environment to avoid moisture or corrosion. Safety precautions: Cut off the power before operation to avoid electric shock. Wear protective gloves during installation and disassembly to prevent scratches. Avoid using in flammable and explosive environments unless the flow meter has anti explosion function.

2. KROHNE IFC300 Electromagnetic Flow Meter Operation Manual: [8]

Overview of the Core Content of the KROHNE IFC300 Electromagnetic Flow Meter Operation Manual This manual mainly covers the usage methods and common troubleshooting solutions of the KROHNE IFC300 electromagnetic flow meter. The following are the key operation and maintenance points:

1. Basic product operation process Installat
