Krohne Mag Flow Meter Operation: Obstructionless Volumetric Measurement for Conductive Liquids
Quick Answer: A Krohne mag flow meter measures volumetric flow in conductive liquids with an obstructionless sensor tube. No moving parts sit in the flow path. The meter applies a magnetic field and reads the voltage generated by the liquid. Silver Instruments supplies electromagnetic flow meters with the same working principle from DN15 to DN2000.
How a Krohne Mag Flow Meter Works
A Krohne mag flow meter follows the Faraday law of induction. Two coils inside the sensor body create a magnetic field across the pipe cross section. Two electrodes sit flush with the liner surface. When a conductive liquid moves through this field, a small voltage appears at the electrodes. The transmitter reads that voltage in millivolts and converts it to flow velocity. It then calculates volumetric flow in m3/h or L/s.
The sensor has no moving parts or gears. The only wetted parts are the liner and the electrodes. This design adds almost no pressure drop. A DN100 meter on a cooling water line can read 0 to 150 m3/h with an accuracy of 0.2 percent to 0.5 percent of reading. Maintenance is mostly limited to electrode cleaning and liner inspection.
Why Obstructionless Flow Measurement Matters
Water and wastewater plants deal with sludge, rags, sand, and stringy solids. A mechanical flow meter can seize. A mag meter has no obstruction to catch these materials. In a raw sewage lift station in the Philippines, a DN150 electromagnetic flow meter ran for two years without liner wear and without a strainer. The previous mechanical meter was pulled out after repeated blockages.
Chemical and food plants also benefit. Acids, caustic soda, brine, and CIP return streams pass through the sensor without clogging. There are no bearings to fail. Pressure loss is very low. This reduces pump energy cost on a long transfer line. For a 24 hour dosing line in Vietnam, the pressure loss across a DN25 mag meter was less than 0.05 bar at 2 m/s.
Conductive Liquid Requirements
A mag flow meter does not read every liquid. The liquid must be electrically conductive. Standard converters require at least 5 µS/cm. Some models can read down to 0.05 µS/cm. Pure oils, hydrocarbons, and fully deionized water are not suitable. Most engineers skip the conductivity check on tap water or seawater because those fluids are well above the minimum.
Temperature and liner selection decide the real operating limit. Standard PTFE liners handle 120 °C. PFA liners handle 150 °C. Electrode choices include 316L stainless steel, Hastelloy C, titanium, and tantalum. For seawater desalination, titanium electrodes with PTFE liners are common. For hydrochloric acid at 40 °C, tantalum electrodes with PFA lining are often used. Silver Instruments can help match the liner and electrode to the liquid composition.
Installation and Pipe Run Notes
Install the sensor in a flooded pipe section. A vertical pipe with upward flow is a good choice for open discharge. Use grounding rings or grounding electrodes on plastic pipes or lined steel pipes. For standard accuracy, allow 5 pipe diameters straight run upstream and 3 diameters downstream. This requirement is lower
Size the meter to the actual velocity. A good continuous velocity range is 0.5 m/s to 10 m/s. If a DN80 meter measures 20 m3/h, the velocity is about 1.1 m/s. That is a suitable range. If the same DN80 meter runs at 0.1 m/s all day, accuracy will be poor. Reduce the meter size or use a reduced bore sensor.
Krohne Operation Compared with Silver Instruments EMF Series
Here is the thing. Krohne mag flow meter operation is familiar to many process teams. The same measuring principle applies to Silver Instruments EMF series. Silver Instruments offers inline sensors from DN15 to DN2000. Wetted materials include PTFE, PFA, hard rubber, and polyurethane. The standard transmitter has 4-20 mA HART, pulse output, and RS485 Modbus RTU. Accuracy is 0.5 percent of reading. A high accuracy model is available at 0.2 percent.
We often see project buyers in Vietnam, Indonesia, the UAE, Mexico, and South Africa comparing Krohne price with Silver Instruments for water and chemical lines. A local agent may not hold stock for the liner and electrode combination you need. Direct supply from Silver Instruments can shorten lead time to 7 to 15 days for standard DN50 to DN300 meters.
Calibration and Field Verification
Every Silver Instruments electromagnetic flow meter leaves the factory with a wet calibration certificate. The calibration rig is traceable to ISO/IEC 17025. The certificate shows the measured error at 10 percent, 25 percent, 50 percent, 75 percent, and 100 percent of full scale. Users can run converter diagnostics in the field. For a chemical plant in Saudi Arabia, we supplied a DN25 PTFE lined meter with a 3.1 material certificate and a calibration report. The same documentation package is available for projects in Southeast Asia and Latin America.
FAQ: Krohne Mag Flow Meter Operation
Does a mag flow meter work with all liquids?
No. It works only with conductive liquids. Oils, hydrocarbons, and pure deionized water are outside the standard operating range.
Can a mag flow meter measure seawater?
Yes. Seawater has high conductivity at roughly 50,000 µS/cm. Titanium electrodes and PTFE or polyurethane liners are common choices.
What pipe sizes does Silver Instruments offer?
Inline electromagnetic flow meters are available from DN15 to DN2000. Flange standards include ANSI, DIN, JIS, and BS.
Does a Krohne mag meter require a long straight run?
No. Use 5 pipe diameters upstream and 3 downstream for standard accuracy. More straight run improves uncertainty only slightly.
How do I request a quote?
Send pipe size DN, liquid type, flow range, operating pressure bar, temperature °C, and conductivity µS/cm. Silver Instruments will recommend a meter and provide a quotation.
Request a Quote from Silver Instruments
Send your pipe size (DN), liquid type, flow range (m3/h or L/h), operating pressure (bar), temperature (°C), and conductivity (µS/cm). Silver Instruments will propose an electromagnetic flow meter with the correct liner and electrode. Contact Tel: +86-25-68650347 or WhatsApp: +86-25-52155837. WeChat: +86 15365082610. You can also send the request through flow-meter.com.au.
