1. Can the target flowmeter be installed vertically?

The target flowmeter can be installed vertically. When installing vertically, the fluid should flow from bottom to top to ensure that the pipeline is always filled with the measured medium. This principle can effectively avoid the decrease in measurement accuracy caused by insufficient fluid in the pipeline, and prevent the occurrence of air pockets in the pipeline from interfering with the measurement results.

2. Applicable scenario scenario: When measuring liquids with special characteristics that are prone to precipitation and crystallization (such as chemical slurries and high concentration solutions), vertical installation can use gravity to prevent medium retention, reduce the adhesion of crystal accumulation to the flowmeter probe or the inner wall of the pipeline, and ensure long-term stable operation of the equipment. Scenario 2: In a space constrained environment, if there is insufficient space for horizontal pipeline installation on site (such as narrow equipment interlayers or dense pipeline areas), vertical installation can save horizontal space and usually does not have a negative impact on measurement performance. The matching of fluid direction and installation posture is the core point, and the feasibility of vertical installation has been widely applied in practical industrial scenarios. It only needs to follow the flow direction requirements to adapt to multiple complex working conditions.

2. Calculation formula for range adjustment of target flowmeter? The target flowmeter is a new type of flow measurement instrument developed based on the measurement principle of the original strain gauge target flowmeter, using the latest capacitive force sensor as the measuring and sensitive transmission element, and utilizing contemporary digital intelligent processing technology. When the medium flows in the Xiaohuo measuring tube, it generates a pressure difference with the target plate due to its own kinetic energy, resulting in a force on the target plate, causing a slight displacement of the target plate. The magnitude of the force is proportional to the square of the medium flow velocity. The mathematical formula is: F=Cd · A ·ρ· V2/2F: the force acting on the target plate Cd: the fluid resistance coefficient A: the axial projection area of the target plate on the measuring tube ρ: the density of the medium under working conditions V: the characteristic flow velocity of the medium in the measuring tube. The force acting on the chain of the target plate is transmitted through the target rod, causing a slight change in the elastic body of the sensor. After circuit conversion, the corresponding electrical signal is output. Please accept if satisfied!!!

3. What are the common advantages and disadvantages of target flow meters

Advantages of target flow meters: 1. The entire instrument structure is sturdy without moving parts, the sensor does not come into contact with the measured medium, there is no component wear, and it is safe and reliable to use; 2. It can be used as an insertable structure, especially suitable for measuring large pipe diameters, high and low pressure gases or liquids, and is easy to disassemble; 3. Multiple anti-corrosion and high/low temperature resistant materials can be selected (such as Hastelloy, titanium, etc.); The entire machine can be made fully sealed without dead corners (welded form), without any leakag
