The working principle of a hot wire air flow meter is to place a heating object in the fluid and measure the flow rate by detecting the temperature or resistance value of the heating object. Specifically, in a hot wire air flow meter, there is a heated object that exchanges heat with the fluid. When the fluid flows through this heating object, it will carry away some of the heat with it. The relationship between heat dissipation and flow rate: When the energy used to heat an object remains constant, the temperature of the object will change due to heat exchange with the fluid flowing through it. The change in temperature is directly related to the mass of fluid flowing through the heating object. The larger the flow, the more heat is carried away, and the lower the temperature of the heating object. The relationship between resistivity and temperature: The resistivity of a heating object is closely related to its temperature. Therefore, by detecting the resistance value of the heating object, its temperature can be indirectly determined, and the flow rate can be further calculated. In summary, the hot wire air flow meter indirectly measures the flow rate of a fluid by measuring the temperature changes of a heating object in the fluid.

2. What are the 5 lines of the air flow meter?

The five wires of the air flow meter: two are intake temperature wires: one is a live wire, one is a signal wire, and the other three are a live wire, one is a ground wire, and one is a signal wire.. An air flow meter is a device that converts the amount of air drawn in into an electrical signal. The advantages of an air flow meter are minimal pressure loss and a wide range of measurable flow rates. The ratio of the max

imum flow rate to the minimum flow rate of an air flow meter is generally above 20:1, and it is suitable for a wide range of industrial pipe diameters, up to 3m. The output signal is linear with the measured flow rate, with high accuracy, and can measure the fluid flow rate of acid, alkali, salt solutions, water, sewage, corrosive liquids, as well as mud and slurry with conductivity ≥ 1 μ s/cm. But air flow meters cannot measure the flow of gas, steam, and purified water. Additional information: Classification of principles of air flow meters Blade type air flow meters The structure of air flow meters is simple and highly reliable; However, the intake resistance is high, the response is slow, and the volume is large. The so-called Karman vortex air flow meter refers to the vortex that occurs downstream of a cylindrical or triangular object when it is placed in the fluid, with two columns of opposite rotation directions and alternating appearances. In the process of generating Karman vortex, the air pressure on both sides of the vortex generator will change, and it will act on the metal foil through the guide hole, causing it to vibrate. When the light from the light-emitting diode shines on the vibrating metal foil, the reflected light on the metal foil received by the phototransistor is modulated by the vortex, and its output is demodulated to obtain a frequency signal representing the air flow rate. The ultrasonic Karman vortex air flowmeter is equipped with ultrasonic transmission probes and reception probes on both sides of the downstream pipeline of the Karman vortex generator. Due to the influence of Karman vortices on air density, the time for ultra trapped mode sound waves to travel from the transmitting probe to
