1. What is the coefficient of WP intelligent flow integrator for vortex flowmeter?
Hello, I am a technician from a vortex flowmeter manufacturer. From the verification report you mentioned above, 4-20mA corresponds to pressure compensation, while 0-1.6MPA must be set in the accumulator. 4-20mA is selected for pressure compensation, and the corresponding pressure range must be set. The lower limit corresponds to 0, and the upper limit corresponds to 1.6MPa. The above step must not be ignored. The following is the issue of the vortex flowmeter coefficient. From your settings, it is normal that the above situation will not occur because the pulse output flowmeter has an inverse relationship between the pulse flowmeter coefficient and the flow rate. Therefore, the larger the flow coefficient, the smaller the flow rate should be. However, the opposite is true for friends. Therefore, it is judged that it is still a problem of pressure setting, which is the compensation mode of the accumulator mentioned above. Choose pressure compensation, 4-20mA, and set the range to 0-1.6Mpa. Let me explain one more thing for you. The coefficient is 335.102m to the negative third power, and I noticed that it is - third power. This means that the unit is L, not cubic meters, which is quite certain. In fact, many integrators also have units to choose from, some default coefficient units are L, while others are cubic meters, with a difference of 1000 times between them. So, always be careful when dealing with disturbances. Sometimes when the flow rate difference is too large, you need to consider the reason for this setting. If it is a pulse coefficient and the flow rate is too small, reduce the coefficient by 1000 times. If it is too
_600x400.jpg)
2. Flow calculation formula for vortex flowmeter
A vortex generator (blocking fluid) is set in the fluid, and regular vortices are alternately generated from both sides of the vortex generator. This type of vortex is called a Karman vortex street.
. Assuming the frequency of vortex occurrence is f, the average velocity of the measured medium flow is U, the width of the vortex generator face is d, and the diameter of the body is D. According to the principle of Karman vortex street, there is the following relationship: f=SrU1/d=SrU/md(1), where U1- the average velocity on both sides of the vortex generator body, m/s； Sr Strouhal number; What is the formula for calculating the frequency and flow rate of a vortex flowmeter? In general, the flow equation of a turbine flowmeter can be divided into two types: practical flow equation and theoretical flow equation. Practical flow equation: qv=f/K formula 1; In the equation qm=qv ρ, qv and qm respectively represent volumetric flow rates, m3/s， Quality flow, kg/s; F is the frequency of the output signal of the flowmeter, Hz; K is the instrument coefficient of the flowmeter, P/m3。 According to the Instrumen
