1. What are the commonly used models of low-pressure and high flow air flow meters? The commonly used low-pressure and high flow air flow meters mainly include thermal gas mass flow meters, Annubar/Velbar flow meters, LWQ series compressed air flow meters, and universal vortex flow meters.
1. Thermal gas mass flowmeter 1 Adaptation scenario: Suitable for low-pressure air metering with low flow rate, wide range, and large diameter, it can directly measure mass flow rate without additional temperature and pressure compensation, and has high sensitivity to low flow rate gases. Performance parameters: accuracy of ± 1.0% to ± 1.5% FS, diameter coverage of DN15 to DN2000, and plug-in models can be adapted to ultra large diameter pipelines for infiltration.
2. Anuba/Veliba flowmeter 1 Installation features: Plug in installation does not require pipe breakage, with minimal pressure loss, suitable for measuring large-diameter air ducts, such as factory ventilation and large fan supply scenarios. Advantages and limitations: The pointer type can be read directly on site, with a simple structure and resistance to temperature and visible car spine pressure, suitable for low budget routine monitoring. However, under conditions containing impurities, it is easy to cause blockage of throttling components and needs to be cleaned regularly.
III. LWQ Series Compressed Air Flow Meter 1. Standard Basis: Developed in accordance with GB/T32021-2015 standard, integrated with temperature, pressure, flow sensors and intelligent flow integrator
2. Performance Features: Excellent low-pressure and high-pressure metering performance, flow range ratio of 20:1, good repeatability, accuracy up to 1.0 level, low pressure lo
3. Model Example: LWQ-25, nominal diameter DN25, starting flow rate ≤ 0.8m ³/h, flow range 2.5-25m ³/h.
.4. Universal Vortex Flow Meter 1 Adaptation scenario: Suitable for low-pressure air metering scenarios with medium to high flow rates, stable flow rates, and relatively stable pipeline pressures. Performance features: no moving parts, low pressure loss, long service life, with temperature and pressure compensation, accuracy of ± 1.0% R, caliber range of DN15 to DN300. Model example: such as Duoqin DVS-DG15F11U, medium is air, DN15 caliber, body material is 304 stainless steel, working pressure is 1.6MPa, can display instantaneous and cumulative flow on site, supports 4-20mA output, 24V power supply, and ensures flow measurement range of 2.8-12m ³/h for sail accuracy.
2. Flow range of vortex flowmeter
The flow range of vortex flowmeter is mainly determined by the sensor diameter and fluid properties. The larger the diameter, the wider the measurable flow range.
. The conventional liquid measurement range is between 0.5m/s and 7m/s flow rate, and the gas measurement range is between 5m/s and 60m/s. 1. Correspondence between caliber and flow rate (under normal temperature water conditions) The flow range is directly related to the instrument caliber, and the following are typical parameters (referring to the product manuals of mainstream domestic manufacturers such as Chuanyi and Ganges in 2023): • DN15: minimum about 1.2 m ³/h, maximum about 15 m ³/h • DN25: minimum about 3 m ³/h, maximum about 40 m ³/h • DN50: minimum about 10 m ³/h, maximum about 150 m ³/h • DN100: minimum about 40 m ³/h, maximum about 650 m ³/h • DN200: minimum about 150 m ³/h, maximum abou
